5KWh 10KWh 20KWh stacked battery batterie 12v 100ah 10 kw battery power supply system all in one energy storage container
|
Battery type
|
LiFePO4
|
|||||
|
Battery working voltage
|
32.5~54.3V
|
|||||
|
Rated energy capacity
|
5KWh
|
|||||
|
Charging/discharge current
|
100A
|
|||||
|
PV input power
|
5.12KW
|
|||||
|
PV input current
|
50A
|
|||||
|
Layers
|
2 layers(including the inverter)
|
|||||
|
MPPT voltage range
|
120V-450Vdc
|
|||||
|
PV voltage range
|
120V-450Vdc
|
|||||
|
Installation method
|
Floor/removable
|
|||||
|
Design life
|
10 years
|
|||||
|
Communication port
|
USB/RS485/WIFI/Bluetooth
|
|||||
|
IP grade
|
IP21(indoor)
|
|||||
分享
Key attributes
Other attributes
Battery Type:LiFePO4
Output Power Range:10~20 kWh
System Type:Wall-mounted
Model Number:DDYTJSG51100-5K-W
Brand Name:Shengri Sunshine
Place of Origin:China
Communication Port:RS485
Protection Class:IP54
Grid connection:Hybrid grid
Battery Type:Lithium Iron phosphate battery
Charge/discharge current:100A/100A
Charge cut off voltage:57.2V
Discharge cut off voltage:43.6v
Warranty:5 years
Cycle life:6000 Cycles(0.5C standard charge)
OEM/ODM:Yes
Controller Type:MPPT
